Highly flexible deformable gel adhesive 2-15 mm (C2TE S1 type). ATLAS ULTRA GEOFLEX recipe contains unique siliceous gel technology. The siliceous gel offers exceptional ability of water retention. The gel fills pores formed at the stage of adhesive binding by the net of inorganic bonds. The accumulation of part of mixing water ensures full cement hydration, regardless the cladding type in use. Owing to the appropriate water management, which is necessary for the binding process completion, gel adhesive assures perfect bonding to substrates.
The main characteristics
- for any type and size of tiles – ceramic, stone, glass, etc.
- for particularly difficult substrates: old tiles, terrazzo, plasterboards, OSB and damp proofing
- the widest range of use: on floor heating, terraces, in swimming pools
- no slip even in case of mega large cladding
- Highly flexible – deformability S1 – compensates substrate deformation and internal stress.
- Wide range of adhesive thickness (2-15 mm) enables:
- thin-coat cladding fixing on even substrates,
- thin-coat cladding fixing on uneven substrates, preceded by substrate floating,
- thick-coat cladding fixing on uneven substrates, with no need of substrate floating.
- No slip of cladding made of tiles of any type, including large size and stone ones – enables fixing the cladding “from the top” with no need of support at the fixing stage.
- Perfect stabilization of large size tiles (even > 1 m²) fixed on horizontal surfaces – tiles do not sink in the mortar layer.
- Foot traffic and grouting just after 12 hours – owing to accelerated process of adhesive setting and drying.
Unique Gel Technology
ATLAS ULTRA GEOFLEX recipe contains unique siliceous gel technology. The siliceous gel offers exceptional ability of water retention.
The use of siliceous gel technology gives foloowing the advantages:
- possibility of fixing cladding of any type, both absorbable and non-absorbable,
- possibility of optimum adaptation of the adhesive consistency to individual contractor’s preferences and actual needs resulting from particular use, by dosing water within a range much wider than in case of traditional adhesives,
- full adhesive spreading beneath tiles, which improves adhesion and bond durability, particularly in case of outdoor use,
- safe cladding fixing on substrates exposed to direct sunlight, both during tiling and adhesive setting (e.g. on balconies, terraces, etc.).
USE
| TYPE OF FIXED CLADDING |
POSSIBILITY OF USE
|
| glazed tiles |
+
|
| terracotta |
+
|
| porcelain-gres tiles |
+
|
| laminated porcelain-gres tiles |
+
|
| natural stone cladding (granite, marble, travertine, syenite, etc.) |
application test required
|
| marble/ natural stone cladding insusceptible to discolouration |
+
|
| clinker |
+
|
| stone |
+
|
| ceramic mosaic |
+
|
| glass mosaic |
application test required
|
| glass, coloured, printed tiles |
application test required,
check tiles manufacturer recommendations
|
| concrete/ cement tiles |
+
|
| composite panels |
+
|
| insulation and acoustic panels |
+
|
*if in doubt conduct an application test and check tiles manufacturer’s guidelines.
| SIZE OF FIXED ELEMENTS |
POSSIBILITY OF USE
|
| small and medium size tiles (< 0.1 m²) |
+
|
| large size tiles (< 0.25 m²) |
+
|
| very large size tiles (> 0.25 m²) |
|
| slim type tiles |
|
Fixing cladding on horizontal and vertical surfaces, indoors and outdoors.
| BUILDING TYPE |
POSSIBILITY OF USE
|
| residential |
+
|
| public access, educational, healthcare, offices |
+
|
| commercial and service |
+
|
| sacral |
+
|
| industrial buildings and multi-storey garages |
+
|
| industrial warehouses |
+
|
| infrastructure |
+
|
| SPA |
+
|
| PLACE TYPE |
POSSIBILITY OF USE
|
| surfaces of low traffic |
+
|
| surfaces of moderate traffic |
+
|
| surfaces of intensive traffic |
+
|
| rooms of limited operational loads in any building type |
+
|
| kitchen, bathroom, laundry, garage (in individual housing) |
+
|
| terraces, balconies, loggia |
+
|
| slab and beam stairs outdoors |
+
|
| showers, washes, rooms washed with plenty of water |
+
|
| communication routes (except of stairs outdoors) |
+
|
| façades (incl. ETICS systems) |
+
|
| cladding on plinths |
+
|
| technological tanks, pools, fountains, jacuzzi, balneotechnology (with no aggressive chemicals in use |
+
|
| sauna |
+
|
| showers, washes, rooms washed with plenty of water |
|
| SUBSTRATE TYPE - standard |
POSSIBILITY OF USE
|
| cement screeds and floors |
+
|
| anhydrite screeds |
+
|
| cement, cement-lime plasters |
+
|
| gypsum plasters |
+
|
| walls made of cellular concrete |
+
|
| walls made of silicate brick or hollow blocks |
+
|
| walls made of ceramic brick or hollow blocks |
+
|
| walls made of gypsum blocks |
|
The product has been given the Radiation Hygiene Certificate.
Detailed guidelines concerning the substrate preparation, depending on its type.
Consumption
Average consumption listed in the table below refers to application upon even substrates. Substrate irregularities increase the actual mortar consumption.
| Size of the tiles | Surface | Recommended notches size | Consumption |
| cm | mm | kg/m2 | |
| 2 x 2 | Wall | 4 | 1.3 |
| Floor | 4 | 1.3 | |
| 10 x 10 | Wall | 4 | 1.3 |
| Floor | 6 | 2.0 | |
| 15 x 60 | Wall | 6 | 2.0 |
| Floor | 8 | 2.5 | |
| 20 x 25 | Wall | 6 | 2.0 |
| Floor | 8 | 2.5 | |
| 25 x 40 | Wall | 6 | 2.0 |
| Floor | 8 | 2.5 | |
| 30 x 30 | Wall | 6 | 2.0 |
| Floor | 8 | 2.5 | |
| 30 x 60 | Wall | 6 | 2.0 |
| Floor | 10 | 3.0 | |
| 40 x 40 | Wall | 8 | 2.5 |
| Floor | 10 | 3.0 | |
| 50 x 50 | Wall | 8 | 2.5 |
| Floor | 10 | 3.0 | |
| 60 x 60 | Wall | 10 | 3.0 |
| Floor | 12 | 3.5 | |
| 100 x 100 | Wall | 10 | 3.5 |
| Floor |
12 (trowel with semi-circular notches) |
4.6 |
Packaging
Foil bags: 5, 25 kg
Pallet: 720 kg in 5 kg bags, 1,200 kg in 25 kg bags
Geoflex products comparison
| Product | GEOFLEX EXPRESS highly flexible rapid set gel adhesive |
GEOFLEX highly flexible gel adhesive |
GEOFLEX WHITE highly flexible gel adhesive |
ULTRA GEOFLEX highly flexible deformable gel adhesive |
| TECHNICAL DATA | ||||
| Standard | PN-EN 12004+A1:2012 | |||
| CLASS | C2FT | C2TE | C2TE | C2TE S1 |
| BONDING STRENGTH (N/mm²) | ≥ 1.0 | ≥ 1.0 | ≥ 1.0 | ≥ 1.0 |
| MIN / MAX ADHESIVE THICKNESS (mm) | 2-15 | 2-15 | 2-15 | 2-15 |
| ADHESIVE PREPARATION TEMPERATURE (°C) | 5-35 | 5-35 | 5-35 | 5-35 |
| READY TO USE AFTER MIXING | approx. 45 minutes (for mixing ratio) 0,24 l/kg) approx. 75 minutes (for mixing ratio 0,3 l/kg) |
approx. 4 hours | approx. 4 hours | approx. 4 hours |
| OPEN TIME (min) | >20 | >30 | >30 | >30 |
| FLOOR ACCESS / GROUTINGF (h) | after 2 | after 12 | after 12 | sfter 12 |
| FULL OPERATION LOAD - FOOT TRAFFIC (h) | 2-6 | 3 | 3 | 3 |
| FULL OPERATION LOAD - VEHICLE TRAFFIC (h) | 24 | 14 | 14 | 14 |
| FLOOR HEATING (days) | 7 | 14 | 14 | 14 |
| SHELF LIFE (months) | 12 | 12 | 12 | 12 |
| CLADDING TYPE | ||||
| GLAZED TILES | + | + | + | + |
| TERRACOTA | + | + | + | + |
| PORCELAIN GRES | + | + | + | + |
| LAMINATED GRES | use ultra geoflex | use ultra geoflex | use ultra geoflex | + |
| NATURAL STONE CLADDING (GRANITE, MARBLE, TRAVERTINE, SYENITE, SLATE, etc.) |
+ carry out application test |
+ carry out application test |
+ | + carry out application test |
| CLINKER | + | + | + | + |
| STONEWARE | + | + | + | + |
| CERAMIC MOSAIC | + | + | + | + |
| GLASS MOSAIC | + carry out application test |
+ carry out application test |
+ carry out application test / check tile's producer's guidings |
+ carry out application test |
| GLASS, COLORED, PRINTED TILES | + carry out application test / check tile's producer's guidings |
+ carry out application test / check tile's producer's guidings |
+ carry out application test / check tile's producer's guidings |
+ carry out application test / check tile's producer's guidings |
| CONCRETE / CEMENT MORTAR TILES | + | + | + | + |
| COMPOSITE TILES | use ultra geoflex | use ultra geoflex | use ultra geoflex | + |
| INSULATION AND SOUND ABSORBING panels |
use ultra geoflex | use ultra geoflex | use ultra geoflex | + |
Type of adhesive:
- Improved cementitious (C2)
- Reduced slip (T)
- Extendend open time (E)
- Deformable (S1)
Place of assembly:
- Floors
- Walls
- Kitchen, bathroom, laundry, garage
- Terraces
- Balconies, loggias
- Passageways, external stairs
- Elevations (including insulation systems)
- Cladding of building plinths
- Pools and fountains
- Potable water tanks
- Saunas
- Showers, car washes, etc.
Types of buildings:
- Housing
- Public facilities
- Commercial and service facilities
- Industrial facilities, multi-level garages
- Warehouses
- Communication facilities
Type of tile:
- Glazing tiles
- Terracotta
- Gres-porcelain
- Laminated gres
- Clinker
- Stoneware wall tiles
- Ceramic mosaic
- Concrete tiles, cement mortar tiles
- Composite tiles
- Insulation and sound absorbing panels
Size of tile:
- up to 0,1 m2
- up to 0,25 m2
- more than 0,25 m2
- "slim" tiles
Layer thickness:
2 - 15mm
